Model:TIN-based Real-time Integrated Basin Simulator (tRIBS)

Edit Model information

TIN-based Real-time Integrated Basin Simulator (tRIBS)

This code has been community reviewed and published in the open access Journal of Open Source Software (JOSS)

Metadata

Summary Contact Technical specs In/Output Process Testing Other Component info Also known as tRIBS Model type Single Model part of larger framework Note on status model Date note status model 2024-05-03 Incorporated models or components: Spatial dimensions 2D Spatial extent Regional-Scale, Landscape-Scale, Watershed-Scale, Reach-Scale, Patch-Scale, Point-Based Model domain Terrestrial, Hydrology, Ecosystems One-line model description The TIN-based Real-Time Integrated Basin Simulator is a fully-distributed, continuous hydrologic model operating on a Triangulated Irregular Network (TIN). Extended model description The tRIBS model in this release (version 5.2.0 of May 3, 2024) under the MIT license includes: Hydrologic Processes: Soil moisture infiltration fronts and their vertical redistribution. Coupled dynamics of the vadose and saturated zones with a dynamic water table. Topography-driven lateral fluxes in the vadose and saturated zones. Radiation and energy balance components on complex terrain. Single layer snowpack accumulation, ablation and melt on complex terrain. Rainfall and snow interception on vegetation canopies. Evaporation of intercepted rainfall, soil evaporation and plant transpiration. Hydrologic hillslope routing, hydraulic routing in channels, level-pool reservoir routing. Computational Processes: Multi-resolution domain generated with channel network and watershed boundary. Computationally-efficient methods for infiltration, snow dynamics and flow routing. Serial operation for point-scale simulations and small watershed domains. Parallelized operation for large domains optimized through subbasin partitioning methods. Ingestion of time-varying meteorological forcing from stations or raster-based products. Ingestion of soil and vegetation parameters from tabular data or raster-based products. Pre- and post-processing workflows for time series and spatial analysis using Python. Keywords: Name Enrique Vivoni Type of contact Technical contact Institute / Organization Arizona State University Postal address 1 Postal address 2 Town / City Tempe Postal code 85287-8704 State Arizona Country United States Email address vivoni@asu.edu Phone Fax Supported platforms Unix, Linux, Mac OS Other platform Programming language C++ Other program language Code optimized Multiple Processors Multiple processors implemented Distributed memory Nr of distributed processors Nr of shared processors Start year development 2000 Does model development still take place? Yes If above answer is no, provide end year model development Code development status Active When did you indicate the 'code development status'? 2024 Model availability As code Source code availability (Or provide future intension) Through web repository Source web address https://github.com/tribshms/tRIBS Source csdms web address Program license type BSD or MIT X11 Program license type other Memory requirements Typical run time Describe input parameters Input format Other input format Describe output parameters Output format Other output format Pre-processing software needed? Yes Describe pre-processing software Python tools, see https://github.com/tribshms/pytRIBS Post-processing software needed? Yes Describe post-processing software Python tools, see https://github.com/tribshms/pytRIBS Visualization software needed? Yes If above answer is yes Other visualization software Python tools, see https://github.com/tribshms/pytRIBS Describe processes represented by the model See https://tribshms.readthedocs.io/en/latest/ Describe key physical parameters and equations See https://tribshms.readthedocs.io/en/latest/ Describe length scale and resolution constraints See https://tribshms.readthedocs.io/en/latest/ Describe time scale and resolution constraints See https://tribshms.readthedocs.io/en/latest/ Describe any numerical limitations and issues See https://tribshms.readthedocs.io/en/latest/ Describe available calibration data sets See https://tribshms.readthedocs.io/en/latest/man/Benchmarks.html Upload calibration data sets if available: Describe available test data sets See https://tribshms.readthedocs.io/en/latest/man/Benchmarks.html Upload test data sets if available: Describe ideal data for testing See https://tribshms.readthedocs.io/en/latest/man/Benchmarks.html Do you have current or future plans for collaborating with other researchers? Is there a manual available? Yes Upload manual if available: Model website if any https://tribshms.readthedocs.io/en/latest/ Model forum / discussion board https://groups.google.com/g/tribs Comments This part will be filled out by CSDMS staff OpenMI compliant No but possible BMI compliant No but possible WMT component No but possible PyMT component No but possible Is this a data component No DOI model 10.5281/zenodo.13324179 For model version v5.2 Year version submitted 2024 Link to file https://zenodo.org/records/13324179 Can be coupled with:

Model info Authors Enrique Vivoni Source code Go to external source code site DOI Download TIN-based Real-time Integrated Basin Simulator (tRIBS) version: v5.2 Doi: 10.5281/zenodo.13324179 Model citations Nr. of publications: 109 Total citations: 5731 h-index: 42 m-quotient: 1.35 QR-code Link to this page Other models by author TIN-based Real-time Integrated Basin Simulator (tRIBS)

References

Automatically enter Reference by DOI

Manually enter Reference

Nr. of publications:	109
Total citations:	5731
h-index:	42
m-quotient:	1.35

Featured publication(s)	Year	Model described	Type of Reference	Citations
Ivanov, Valeriy Y.; Vivoni, Enrique R.; Bras, Rafael L.; Entekhabi, Dara; 2004. Catchment hydrologic response with a fully distributed triangulated irregular network model. Water Resources Research, 40, None. 10.1029/2004WR003218 (View/edit entry)	2004	TIN-based Real-time Integrated Basin Simulator (tRIBS)	Source code ref.	322
Raming, L.W.; Vivoni, E.R.; Mascaro, G.; Cederstrom, C.J.; Ko, A.; Schreiner-McGraw, A.P.; Lizarraga-Celaya, C.; 2024. tRIBS v5.2: A multi-resolution, parallel platform for tributary hydrology in forest applications. Journal of Open Source Software, 9, . 10.21105/joss.06747 (View/edit entry)	2024	TIN-based Real-time Integrated Basin Simulator (tRIBS)	Model overview	0
Vivoni, Enrique R.; Mascaro, Giuseppe; Mniszewski, Susan; Fasel, Patricia; Springer, Everett P.; Ivanov, Valeriy Y.; Bras, Rafael L.; 2011. Real-world hydrologic assessment of a fully-distributed hydrological model in a parallel computing environment. Journal of Hydrology, 409, 483–496. 10.1016/j.jhydrol.2011.08.053 (View/edit entry)	2011	TIN-based Real-time Integrated Basin Simulator (tRIBS)	Model overview	105
See more publications of TIN-based Real-time Integrated Basin Simulator (tRIBS)
