Model:LITHFLEX2

LITHFLEX2

Also known as
Model type	Single
Model part of larger framework
Note on status model
Date note status model

Incorporated models or components:

Spatial dimensions	1D
Spatial extent
Model domain	Geodynamic
One-line model description	Lithospheric flexure solution for a broken plate
Extended model description	Lithospheric flexure solution for a broken plate. Load is assumed to be represented by equal width loading elements specified distance from broken edge of plate. Inclusion of sediments as part of the restoring force effect is possible by choice of density assigned to density (2).

Keywords:	lithospheric flexure, broken plate,

Supported platforms	Unix, Linux, Mac OS, Windows
Other platform
Programming language	Fortran77
Other program language
Code optimized	Single Processor
Multiple processors implemented
Nr of distributed processors
Nr of shared processors
Start year development	1992
Does model development still take place?	No
If above answer is no, provide end year model development	1994
Code development status	As is, no updates are provided
When did you indicate the 'code development status'?	2020
Model availability	As code
Source code availability (Or provide future intension)	Through CSDMS repository
Source web address
Source csdms web address	https://github.com/csdms-contrib/lithflex
Program license type	Other
Program license type other	--
Memory requirements	<512MB
Typical run time	A few seconds

Describe input parameters	Width of loading element (m), value for flexural rigidity (Nm), Number of loading events, Number of loading elements for event J (position, height (m) of loading element, density (kg/m3))
Input format	ASCII
Other input format
Describe output parameters	Amount of deflection of the crust as a function of horizontal position
Output format	ASCII
Other output format
Pre-processing software needed?	No
Describe pre-processing software
Post-processing software needed?	No
Describe post-processing software
Visualization software needed?	Yes
If above answer is yes
Other visualization software	Any software that can read ASCII data

Describe processes represented by the model	1D flexure of a broken elastic plate
Describe key physical parameters and equations	See Slingerland et al. (1994)
Describe length scale and resolution constraints	--
Describe time scale and resolution constraints	--
Describe any numerical limitations and issues	--

Describe available calibration data sets	See Slingerland et al. (1994)
Upload calibration data sets if available:
Describe available test data sets
Upload test data sets if available:
Describe ideal data for testing

Do you have current or future plans for collaborating with other researchers?	None

Is there a manual available?	No
Upload manual if available:
Model website if any
Model forum / discussion board

Comments

This part will be filled out by CSDMS staff

Can be coupled with:

Model info

Authors

Kevin Furlong

Source code

Model citations

QR-code

Link to this page

Other models by author

Featured publication(s)	Year	Model described	Type of Reference	Citations
Slingerland, R.L.; Furlong, K.; Harbaugh, J.; 2008. Simulating Clastic Sedimentary Basins/Physical Fundamentals and Computing Procedures. In: (eds.).. 352. (View/edit entry)	2008	2DFLOWVEL BEDLOAD DELTA ENTRAIN ENTRAINH FLDTA LITHFLEX1 LITHFLEX2 LOGDIST LONGPRO MIDAS SETTLE STORM STVENANT SUSP SVELA TURB WAVEREF WINDSEA YANGs	Model application	31
See more publications of LITHFLEX2
