Model:IHydroSlide3D

IHydroSlide3D

Also known as
Model type	Single
Model part of larger framework
Note on status model
Date note status model

Incorporated models or components:

Spatial dimensions	3D
Spatial extent
Model domain	Terrestrial, Hydrology
One-line model description	iHydroSlide3D: the integrated Hydrological processes and 3-Dimensional landSlide prediction model
Extended model description	iHydroSlide3D v1.0 is a physically based modeling framework that accounts for both hydrological and geotechnical processes. The model mainly includes the following modules: (i) a distributed hydrological model based on the Coupled Routing and Excess STorage (CREST) model, (ii) a newly developed 3D landslide model, and (iii) a soil moisture downscaling method.

Keywords:	landslides, soil moisture, hydrological,

Supported platforms	Linux, Windows
Other platform
Programming language	Matlab
Other program language
Code optimized	Multiple Processors
Multiple processors implemented
Nr of distributed processors
Nr of shared processors
Start year development	2022
Does model development still take place?	Yes
If above answer is no, provide end year model development
Code development status	As is, no updates are provided
When did you indicate the 'code development status'?	2024
Model availability	As code
Source code availability (Or provide future intension)	Through web repository
Source web address	https://github.com/GuodingChen/iHydroSlide3D_v1.0
Source csdms web address
Program license type	Other
Program license type other	Unlicense license
Memory requirements	--
Typical run time	--

Describe input parameters	ET, Topography, landcover, soil texture
Input format	ASCII, Binary
Other input format
Describe output parameters	overland runoff, soil moisture, and infiltration information, and landslide assessments (FSPFVL and AL).
Output format	Binary
Other output format
Pre-processing software needed?	No
Describe pre-processing software
Post-processing software needed?	No
Describe post-processing software
Visualization software needed?	No
If above answer is yes
Other visualization software

Describe processes represented by the model
Describe key physical parameters and equations
Describe length scale and resolution constraints
Describe time scale and resolution constraints
Describe any numerical limitations and issues

Describe available calibration data sets
Upload calibration data sets if available:
Describe available test data sets
Upload test data sets if available:
Describe ideal data for testing

Do you have current or future plans for collaborating with other researchers?

Is there a manual available?	No
Upload manual if available:
Model website if any
Model forum / discussion board

Comments

This part will be filled out by CSDMS staff

Can be coupled with:

Model info

Authors

Guoding Chen

Source code

DOI

Model citations

QR-code

Link to this page

Other models by author

Featured reference(s)	Open Access Status	Year	Type of Reference	Cited
Chen, G.; Zhang, K.; Wang, S.; Xia, Y.; Chao, L.; 2023. iHydroSlide3D v1.0: an advanced hydrological–geotechnical model for hydrological simulation and three-dimensional landslide prediction. Geoscientific Model Development, 162915–2937. 10.5194/gmd-16-2915-2023	cc-by · publishedVersion	2023	a module overview describing a module	46
