Model:CosmoLand

From CSDMS


CosmoLand


Metadata

Also known as
Model type Single
Model part of larger framework
Note on status model
Date note status model
Incorporated models or components:
Spatial dimensions 2D
Spatial extent
Model domain Terrestrial
One-line model description 2-D model tracking cosmogenic nuclides and mixing in landslide terrain
Extended model description The model tracks both surface CRN concentration and concentration eroded off hillslopes into fluvial network in a simplified landscape undergoing both landslide erosion and more steady 'diffusive-like' erosion. Sediment mixing is allowed in the fluvial network. Code can be used to help successfully develop CRN sampling procedures in terrains where landslides are important.
Keywords:

landscape evolution, landslides, cosmogenic radionuclides,

Name Brian Yanites
Type of contact Model developer
Institute / Organization University of Colorado
Postal address 1 2200 Colorado Ave.
Postal address 2 Campus Box 399
Town / City Boulder
Postal code 80309
State Colorado
Country United States
Email address brian.yanites@colorado.edu
Phone 303-895-9957
Fax


Supported platforms
Linux, Mac OS, Windows
Other platform
Programming language

Matlab

Other program language
Code optimized Single Processor
Multiple processors implemented
Nr of distributed processors
Nr of shared processors
Start year development 2005
Does model development still take place? No
If above answer is no, provide end year model development 2008
Code development status
When did you indicate the 'code development status'?
Model availability As code
Source code availability
(Or provide future intension)
Through CSDMS repository
Source web address
Source csdms web address https://github.com/csdms-contrib/cosmoland
Program license type Other
Program license type other --
Memory requirements <512MB
Typical run time minutes to days


Describe input parameters Input:
  • Landslide: recurrence interval, size parameters
  • Cosmogenic: production rate, decay rate, attenuation, density diffusive erosion rate drainage basin size, critical drainage area for a channel
  • River channel scaling parameters: width, sediment depth, drainage density
Input format
Other input format matlab .m file
Describe output parameters Mass, atoms, landslide size, fluvial residence time, mixed mass and atoms fraction
Output format
Other output format .mat file
Pre-processing software needed? No
Describe pre-processing software
Post-processing software needed? No
Describe post-processing software
Visualization software needed? Yes
If above answer is yes Matlab
Other visualization software


Describe processes represented by the model Tracking of cosmogenic nuclides on surface and in fluvial system of a landslide dominated drainage basin
Describe key physical parameters and equations Cosmogenic nuclide production decay with depth. Power-law distribution of landslide size. Calculates a fluvial storage reservoir.
Describe length scale and resolution constraints Drainage basin size controls the length of the model runs. Cell size should not be increased to shorten model runs.
Describe time scale and resolution constraints Yearly timesteps. Most runs go for 500,000 yrs or more.
Describe any numerical limitations and issues Matlab may max out memory if drainage basin is too large. Since this is a simplified landscape with wrap-around boundary conditions, one workaround is to do numerous smaller runs and add the output.


Describe available calibration data sets
Upload calibration data sets if available:
Describe available test data sets
Upload test data sets if available:
Describe ideal data for testing CRN data both hillslope and fluvial.


Do you have current or future plans for collaborating with other researchers? Not currently.
Is there a manual available? No
Upload manual if available:
Model website if any
Model forum / discussion board
Comments


This part will be filled out by CSDMS staff

OpenMI compliant No but possible
BMI compliant No but possible
WMT component No but possible
PyMT component
Is this a data component
Can be coupled with:
Model info
Nr. of publications: 1
Total citations: 174
h-index: 1
m-quotient: 0.06

Link to this page



Introduction

History

References




Nr. of publications: 1
Total citations: 174
h-index: 1
m-quotient: 0.06



Featured publication(s)YearModel describedType of ReferenceCitations
Yanites, B.J.; Tucker, G.E.; Anderson, R.S. 2009. Numerical and analytical models of cosmogenic radionuclide dynamics in landslide-dominated drainage basins. Journal of Geophysical Research - Earth Surface, 114, . 10.1029/2008JF001088
(View/edit entry)
2009 CosmoLand
Model overview 174
See more publications of CosmoLand
