Model:CoAStal Community-lAnDscape Evolution (CASCADE) model

From CSDMS


CoAStal Community-lAnDscape Evolution (CASCADE) model


Metadata

Also known as CASCADE
Model type Modular
Model part of larger framework
Note on status model
Date note status model
Incorporated models or components:

Barrier3D, Barrier Inlet Environment (BRIE) Model,

Spatial dimensions 3D
Spatial extent Landscape-Scale
Model domain Coastal, Human dimensions
One-line model description A coupled landscape and human-dynamics modeling framework for barrier evolution
Extended model description CASCADE combines elements of two exploratory morphodynamic models of barrier evolution -- barrier3d (Reeves et al., 2021) and the BarrierR Inlet Environment (brie) model (Nienhuis & Lorenzo-Trueba, 2019) -- into a single model framework. Barrier3d, a spatially-explicit cellular exploratory model, is the core of CASCADE. It is used within the CASCADE framework to simulate the effects of individual storm events and SLR on shoreface evolution; dune dynamics, including dune growth, erosion, and migration; and overwash deposition by individual storms. BRIE is used to simulate large-scale coastline evolution arising from alongshore sediment transport processes; this is accomplished by connecting individual Barrier3d models through diffusive alongshore sediment transport. Human dynamics are incorporated in cascade in two separate modules. The first module simulates strategies for preventing roadway pavement damage during overwashing events, including rebuilding roadways at sufficiently low elevations to allow for burial by overwash, constructing large dunes, and relocating the road into the barrier interior. The second module incorporates management strategies for maintaining a coastal community, including beach nourishment, dune construction, and overwash removal.
Keywords:

barrier island, barrier island management, coastal morphodynamics, sea-level rise, coastal evolution,

Name Katherine Anarde
Type of contact Model developer
Institute / Organization North Carolina State University
Postal address 1
Postal address 2
Town / City Raleigh
Postal code 27606
State North Carolina
Country United States
Email address kanarde@ncsu.edu
Phone
Fax


Name Laura Moore
Type of contact Model developer
Institute / Organization University of North Carolina at Chapel Hill
Postal address 1
Postal address 2
Town / City
Postal code
State
Country United States
Email address
Phone
Fax


Name Brad Murray
Type of contact Model developer
Institute / Organization Duke University
Postal address 1
Postal address 2
Town / City
Postal code
State
Country United States
Email address
Phone
Fax


Name Ian Reeves
Type of contact
Institute / Organization United States Geological Survey
Postal address 1
Postal address 2
Town / City
Postal code
State
Country United States
Email address
Phone
Fax


Name Eric Hutton
Type of contact Model developer
Institute / Organization University of Colorado at Boulder
Postal address 1
Postal address 2
Town / City
Postal code
State
Country United States
Email address
Phone
Fax


Name Zachary Williams
Type of contact Model developer
Institute / Organization Duke University
Postal address 1
Postal address 2
Town / City
Postal code
State
Country United States
Email address
Phone
Fax


Supported platforms
Unix, Linux, Mac OS, Windows
Other platform
Programming language

Python

Other program language
Code optimized Multiple Processors
Multiple processors implemented
Nr of distributed processors
Nr of shared processors
Start year development 2019
Does model development still take place? Yes
If above answer is no, provide end year model development
Code development status Active
When did you indicate the 'code development status'? 2024
Model availability As code, As teaching tool
Source code availability
(Or provide future intension)
Through web repository, Through CSDMS repository
Source web address https://github.com/UNC-CECL/CASCADE
Source csdms web address
Program license type BSD or MIT X11
Program license type other
Memory requirements
Typical run time


Describe input parameters
Input format
Other input format
Describe output parameters
Output format
Other output format
Pre-processing software needed? No
Describe pre-processing software
Post-processing software needed? No
Describe post-processing software
Visualization software needed? No
If above answer is yes
Other visualization software


Describe processes represented by the model The effects of individual storm events and SLR on shoreface evolution; dune dynamics, including dune growth, erosion, and migration; overwash deposition by individual storms; large-scale coastline evolution arising from alongshore sediment transport processes; and human management activities.
Describe key physical parameters and equations
Describe length scale and resolution constraints
Describe time scale and resolution constraints
Describe any numerical limitations and issues


Describe available calibration data sets See testing description on github.
Upload calibration data sets if available:
Describe available test data sets
Upload test data sets if available:
Describe ideal data for testing


Do you have current or future plans for collaborating with other researchers?
Is there a manual available? No
Upload manual if available:
Model website if any
Model forum / discussion board
Comments


This part will be filled out by CSDMS staff

OpenMI compliant Not yet"Not yet" is not in the list (Yes, No but planned, No but possible, No not possible) of allowed values for the "Code openmi compliant or not" property.
BMI compliant Not yet"Not yet" is not in the list (Yes, No but planned, No but possible, No not possible) of allowed values for the "Code IRF or not" property.
WMT component Not yet"Not yet" is not in the list (Yes, In progress, No but possible, No not possible) of allowed values for the "Code CMT compliant or not" property.
PyMT component Not yet"Not yet" is not in the list (Yes, In progress, No but possible, No not possible) of allowed values for the "Code PyMT compliant or not" property.
Is this a data component No
Can be coupled with:
Model info
Katherine Anarde
Moore, Murray, Reeves, Hutton, Williams
Nr. of publications: --
Total citations: 0
h-index: --"--" is not a number.
m-quotient: 0
