[edit] Sedtrans05
Contents |
[edit] Metadata
| Modeler information | |
|---|---|
| First name | Urs |
| Last name | Neumeier |
| Type of contact | Model developer |
| Institute / Organization | Institut des sciences de la mer de Rimouski |
| Postal address 1 | Université du Québec à Rimouski |
| Postal address 2 | 310, allée des Ursulines |
| Town / City | Rimouski QC |
| Postal code | G5L 3A1 |
| State | NO STATE |
| Country | Canada |
| Email address | urs_neumeier@uqar.qc.ca |
| Phone | 1-418-7231986#1278 |
| Fax | 1-418-7241842 |
| Additional modeler information | |
|---|---|
| First name | Carl |
| Last name | Amos |
| Type of contact | Model developer |
| Institute / Organization | |
| Postal address 1 | |
| Postal address 2 | |
| Town / City | |
| Postal code | |
| State | |
| Country | |
| Email address | |
| Phone | |
| Fax | |
| Additional modeler information | |
|---|---|
| First name | Christian |
| Last name | Ferrarin |
| Type of contact | Model developer |
| Institute / Organization | |
| Postal address 1 | |
| Postal address 2 | |
| Town / City | |
| Postal code | |
| State | |
| Country | |
| Email address | |
| Phone | |
| Fax | |
| Model identity | |
|---|---|
| Model type | Single |
| Spatial dimensions | |
| Spatial extent | |
| Model domain | |
| One-line model description | Sediment transport model for continental shelf and estuaries |
| Extended model description | Sedtrans05 is a sediment transport model for continental shelf and estuaries. It predicts the sediment transport at one location as function water depth, sediment type, current and waves (single point model). It can be used as sediment transport module for larger 2D models.
Five different transport equations are available for non-cohesive sediments (sand) and one algorithm for cohesive sediment. |
| Model technical information | |
|---|---|
| Supported platforms | Unix, Linux, Windows |
| Other platform | |
| Programming language | Fortran77 |
| Other program language | |
| Code optimized | |
| Start year development | 1984 |
| Does model development still take place? | Yes |
| If above answer is no, provide end year model development | |
| Model availability | As code |
| Source code availability (Or provide future intension) | Through owner |
| Source web address | |
| Program license type | GPL v3 |
| Program license type other | |
| OpenMI compliant | No but possible |
| CCA component | No but possible |
| IRF interface | No but possible |
| Memory requirements | -- |
| Typical run time | -- |
| Input - Output description | |
|---|---|
| Describe input parameters | water depth, current speed at height z, current direction, wave height, wave period, wave direction, median grain-size, bed slope, sediment density, salinity, temperature |
| Input format | ASCII |
| Other input format | interface function from Matlab |
| Describe output parameters | sediment transport rate, direction of sediment transport, bedforms, and several intermediate results (settling velocity, threshold of movements , bed shear stress, etc.) |
| Output format | ASCII |
| Other output format | interface junction from Matlab |
| Pre-processing software needed? | No |
| Describe pre-processing software | |
| Post-processing software needed? | No |
| Describe post-processing software | |
| Visualization software needed? | No |
| If above answer is yes | |
| Other visualization software | |
| Process description model | |
|---|---|
| Describe processes represented by the model | Bed boundary layer for pure current, combined current and waves, and pure waves.
Transport of non-cohesive sediment. Erosion, transport and deposition of cohesive sediment. |
| Describe key physical parameters and equations | The model uses hydrodynamics parameters, sediment characteristics (median grain size, density, possibly pre-existing bedforms), and water characteristics (viscosity and density computed from salinity and temperature)
It uses Grant and Madsen (1986) continental shelf bottom boundary layer theory. Five methods to predict sediment transport for non-cohesive sediments are offered: Einstein-Brown (Brown, 1950), Yalin (1963) and Van Rijn (1993) Engelund and Hansen (1967) and Bagnold (1963). |
| Describe length scale and resolution constraints | -- |
| Describe time scale and resolution constraints | -- |
| Describe any numerical limitations and issues | -- |
| Model testing | |
|---|---|
| Describe available calibration data sets | -- |
| Upload calibration data sets if available: | |
| Describe available test data sets | -- |
| Upload test data sets if available: | |
| Describe ideal data for testing | -- |
| Users groups model | |
|---|---|
| Do you have current or future plans for collaborating with other researchers? | -- |
| Documentation model | |
|---|---|
| Provide key papers on model if any | Neumeier U., Ferrarin C., Amos C.L., Umgiesser G., Li M.Z. (2008) Sedtrans05: An improved sediment-transport model for continental shelves and coastal waters with a new algorithm for cohesive sediments. Computer & Geosciences, 34, 1223-1242. doi:10.1016/j.cageo.2008.02.007 |
| Is there a manual available? | Yes |
| Upload manual if available: | |
| Model website if any | http://labsedim.uqar.ca/sedtrans05 |
| Model forum / discussion board | |
| Additional comments | |
|---|---|
| Comments | The computation routines can be accessed from different interfaces: a console program for batch-processing data from The computation routines can be accessed from different interfaces: a console program for batch-processing data from file or for interactively entering data, a graphic user interface for Microsoft Windows (especially useful for teaching or exploring the model), a Matlab MEX function to call Sedtrans05 directly from Matlab. The FORTRAN77 routines can also easily called from other programs. |
